Medium DMC-S (1778 mm Y-axis)
Please scroll left and right for full information
| Item / Model | DMC-2100S (No.40) | DMC-2100SH (No.50) | DMC-2600S (No.40) | DMC-2600SH (No.50) | DMC-3100S (No.40) | DMC-3100SH (No.50) | DMC-4100S (No.40) | DMC-4100SH (No.50) | DMC-5100S (No.40) | DMC-5100SH (No.50) | DMC-6100S (No.40) | DMC-6100SH (No.50) |
| Distance between columns (mm) | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") | 1796(70.7") |
| Table size (mm) | 2200x1500(86.6"x59") | 2200x1500(86.6"x59") | 2700x1500(106.2"x59") | 2700x1500(106.2"x59") | 3200x1500(126"x59") | 3200x1500(126"x59") | 4200x1500(165.4"x59") | 4200x1500(165.4"x59") | 5200x1500(204.7"x59") | 5200x1500(204.7"x59") | 6200x1500(244.1"x59") | 6200x1500(244.1"x59") |
| X axis travel (mm) | 2100(82.7") | 2100(82.7") | 2600(102.4") | 2600(102.4") | 3100(122") | 3100(122") | 4100(161.4") | 4100(161.4") | 5100(200.7") | 5100(200.7") | 6100(240.2") | 6100(240.2") |
| Y axis travel (mm) | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") | 1778(70") |
| Z axis travel (mm) | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") | 800(31.5") |
| Spindle nose to table (mm) | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") | 150~950(5.9"~37.4") |
| Spindle taper | BT-40 / CAT-40 ; HSK A63(Opt.) | BT-50 / CAT-50 ; HSK A100(Opt.) | BT-40 / CAT-40 ; HSK A63(Opt.) | BT-50 / CAT-50 ; HSK A100(Opt.) | BT-40 / CAT-40 ; HSK A63(Opt.) | BT-50 / CAT-50 ; HSK A100(Opt.) | BT-40 / CAT-40 ; HSK A63(Opt.) | BT-50 / CAT-50 ; HSK A100(Opt.) | BT-40 / CAT-40 ; HSK A63(Opt.) | BT-50 / CAT-50 ; HSK A100(Opt.) | BT-40 / CAT-40 ; HSK A63(Opt.) | BT-50 / CAT-50 ; HSK A100(Opt.) |
| Spindle diameter (Bearing) (mm) | 70(2.8") | 90(3.5") | 70(2.8") | 90(3.5") | 70(2.8") | 90(3.5") | 70(2.8") | 90(3.5") | 70(2.8") | 90(3.5") | 70(2.8") | 90(3.5") |
| Spindle speed (rpm) | 8000;10000/12000(Opt.) 15000,18000,20000(Opt.) | 6000 ; 10000 | 8000;10000/12000(Opt.) 15000,18000,20000(Opt.) | 6000 ; 10000 | 8000,10000 ; 12000(Opt.) | 6000 ; 10000 | 8000,10000 ; 12000(Opt.) | 6000 ; 10000 | 8000,10000 ; 12000(Opt.) | 6000 ; 10000 | 8000,10000 ; 12000(Opt.) | 6000 ; 10000 |
| Spindle motor (kW) | 7.5 / 11 Hi Lo Gear ; 18.5 / 23 Built-in | 22 / 26 Hi Lo Gear ; 26 / 31 or 31 / 40 Built-in | 7.5 / 11 Hi Lo Gear ; 18.5 / 23 Built-in | 22 / 26 Hi Lo Gear ; 26 / 31 or 31 / 40 Built-in | 7.5 / 11 Hi Lo Gear ; 18.5 / 23 Built-in | 22 / 26 Hi Lo Gear ; 26 / 31 or 31 / 40 Built-in | 7.5 / 11 Hi Lo Gear ; 18.5 / 23 Built-in | 22 / 26 Hi Lo Gear ; 26 / 31 or 31 / 40 Built-in | 7.5 / 11 Hi Lo Gear ; 18.5 / 23 Built-in | 22 / 26 Hi Lo Gear ; 26 / 31 or 31 / 40 Built-in | 7.5 / 11 Hi Lo Gear ; 18.5 / 23 Built-in | 22 / 26 Hi Lo Gear ; 26 / 31 or 31 / 40 Built-in |
| X-Y-Z Rapid traverse (m/min) | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") | 12 / 12 / 12 (472" / 472" / 472") |
| X-Y-Z cutting feed (mm/min) | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 | 1~10000 |
| ATC-Adjacent pockets max. tool dia. (mm) | Φ75 (Φ3") | Φ125 (Φ5") | Φ75 (Φ3") | Φ125 (Φ5") | Φ75 (Φ3") | Φ125 (Φ5") | Φ75 (Φ3") | Φ125 (Φ5") | Φ75 (Φ3") | Φ125 (Φ5") | Φ75 (Φ3") | Φ125 (Φ5") |
| ATC-No. of tools | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) | Arm type 24 ; 32 / 40 (Opt.) |
| ATC-Max. tool diameter (mm) | Φ100 (Φ4") | Φ200 (Φ7.8") | Φ100 (Φ4") | Φ200 (Φ7.8") | Φ100 (Φ4") | Φ200 (Φ7.8") | Φ100 (Φ4") | Φ200 (Φ7.8") | Φ100 (Φ4") | Φ200 (Φ7.8") | Φ100 (Φ4") | Φ200 (Φ7.8") |
| ATC-Max. tool length (mm) | 320 (12.6") | 400 (15.7") | 320 (12.6") | 400 (15.7") | 320 (12.6") | 400 (15.7") | 320 (12.6") | 400 (15.7") | 320 (12.6") | 400 (15.7") | 320 (12.6") | 400 (15.7") |
| ATC-Max. tool weight (kg) | 10 (22 lb) | 15 (33 lb) | 10 (22 lb) | 15 (33 lb) | 10 (22 lb) | 15 (33 lb) | 10 (22 lb) | 15 (33 lb) | 10 (22 lb) | 15 (33 lb) | 10 (22 lb) | 15 (33 lb) |
| ATC-Tool selection | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path | Bi-direction random type, Shortest path |
| Table load capacity (kg) | 10000 (22000 lb) | 10000 (22000 lb) | 10000 (22000 lb) | 10000 (22000 lb) | 10000 (22000 lb) | 10000 (22000 lb) | 10000 (22000 lb) | 10000 (22000 lb) | 12000 (26400 lb) | 12000 (26400 lb) | 14000 (30800 lb) | 14000 (30800 lb) |
| Dimensions (LxWxH) (mm) | 6633 x 4600 x 3883 (261.1"x181.1"x152.9") | 6633 x 4600 x 3883 (261.1"x181.1"x152.9") | 7661 x 4600 x 3883 (301.6"x181.1"x152.9") | 7661 x 4600 x 3883 (301.6"x181.1"x152.9") | 8693 x 4600 x 3883 (342.2"x181.1"x152.9") | 8693 x 4600 x 3883 (342.2"x181.1"x152.9") | 11590 x 4600 x 4013 (456.3"x181.1"x158") | 11590 x 4600 x 4013 (456.3"x181.1"x158") | 13666 x 4600 x 4013 (538"x181.1"x158") | 13666 x 4600 x 4013 (538"x181.1"x158") | 15590 x 4600 x 4013 (613.8"x181.1"x158") | 15590 x 4600 x 4013 (613.8"x181.1"x158") |
| Machine Weight (kg) | 22800 (50220 lb) | 22800 (50220 lb) | 24400 (53745 lb) | 24400 (53745 lb) | 26000 (57270 lb) | 26000 (57270 lb) | 37500 (82500 lb) | 37500 (82500 lb) | 42100 (92620 lb) | 42100 (92620 lb) | 47000 (103525 lb) | 47000 (103525 lb) |
All the specifications above are subject to change without prior notice.
Standard Accessories
- External coolant supply system 2 bar with spindle nozzles
- Spindle air blast
- Heat exchanger (std. for Fanuc only)
- AC for electric cabinet (std. for Siemens only)
- 2 pcs of screw type + 1 pc of chain type chip conveyor with trolley
- 1 complete set of machine manuals
- Toolbox for basic maintenance
- Foundation bolts and levelling pads
- Rigid tapping
- Oil cooler for spindle & gearbox
- Auto centralized lubrication system with alarms
- Fanuc 0i-MF PLUS with 10.4” LCD + Manual Guide i for basic machine configuration
- Full enclosure
- LED working lights
- 24-tool arm type ATC
Optional Accessories
- Auto tool touch probe Renishaw TS-27R
- Auto laser tool probe Renishaw NC4
- Workpiece measuring device Renishaw OMP60 (contact type)
- Workpiece measuring device Renishaw RMP60 (laser type)
- High pressure coolant thru tool tip 20 bar with cartridge type filtration system
- High pressure coolant thru spindle 20 bar with cartridge type filtration system
- Paper filtration system
- Scraper type chip conveyor with magnetic separator
- 32, 40, 60-tool ATC or above
- Siemens SINUMERIK 828D control system
- Fanuc 31i-MB PLUS or Siemens SINUMERIK ONE control system
- Fagor or Mitsubishi controllers are also available
- Linear scales on X, Y or Z axes
- 15000 ,18000 ,20000 rpm for HSK A63 built-in spindle
- 10000 rpm for HSK A100 built-in spindle
- Thermal compensation system on spindle
- 5-Face milling head
- NC 2-Axis milling head
- Universal milling head
- Orthogonal milling head
